The RS 2 PRO gimbal is a redesigned follow-up to the Ronin-S gimbal with a payload of up to 10 lb. It's about 25% lighter and more compact thanks to monocoque carbon fiber axis arms and a shorter grip handle with a smaller battery cartridge, although still with a 12-hour runtime.
| Gimbal |
| BG30 Grip |
| USB-C Charging Cable (40 cm) |
| Lens-Fastening Strap |
| Extended Grip/Tripod (Metal) |
| Quick-Release Plate (Arca-Swiss/Manfrotto) |
| Briefcase Handle |
| Camera Riser |
| Carrying Case |
| Multi-Camera Control Cable (USB-C, 30 cm) |
| Multi-Camera Control Cable (Sony Multi, 30 cm) |
| Multi-Camera Control Cable (Micro-USB, 30 cm) |
| Multi-Camera Control Cable (Mini-USB, 30 cm) |
| Hook-and-Loop Strap |
| D-Ring Camera Mounting Screw 1/4″-20 |
| RSA/NATO Port Cover |
| Pan Axis Sleeve |
| Screw 1/4″-20 |
| Phone Holder (Pro Kit) |
| Focus Motor (Pro Kit) |
| Focus Motor Rod Mount Kit (Pro Kit) |
| Focus Gear Strip (Pro Kit) |
| Image Transmitter (Pro Kit) |
| Cold Shoe to 1/4”-20 Adapter (Pro Kit) |
| USB-C Power Cable (20 cm) (Pro Kit) |
| Mini-HDMI to HDMI Cable (20 cm) (Pro Kit) |
| Mini-HDMI to Mini-HDMI Cable (20 cm) (Pro Kit) |
| Mini-HDMI to Micro-HDMI Cable (20 cm) (Pro Kit) |
| M4 Screw (10 mm) (Pro Kit) |
| Allen Wrench (3 mm) (Pro Kit) |
| Number of Axes 3-Axis (Pitch, Roll, Yaw) |
| Rotation Range |
| Yaw (Pan): 360° |
| Pitch (Tilt): -112 to 214° |
| Roll: -95 to 240° |
| Follow Speed |
| Pan: 360°/s |
| Tilt: 360°/s |
| Roll: 360°/s |
| Load Capacity 10 lb / 4.5 kg |
| Ports |
| 2 x RSA |
| 3 x USB Type-C |
| Wireless Frequency 2.4 GHz (2.4 – 2.483) |
| Wireless Protocol Bluetooth 5.0 |
| Battery Capacity (mAh) 1950 mAh |
| Battery Capacity (Wh) 30.3 Wh |
| Battery Runtime 12 Hours |
| Battery Chemistry Lithium-Ion Polymer (LiPo) |
| Voltage 15.4 VDC |
| Operating Temperature -4 to 113°F / -20 to 45°C |
| Materials Aluminum, Carbon Fiber, Plastic |
| Dimensions 16.1 x 10.2 x 7.7″ / 410 x 260 x 195 mm |
| Weight |
| 2.36 lb / 1.07 kg |
| 2.595 lb / 1.177 kg (with Camera Plate) |
| 2.948 lb / 1.337 kg (with Handlebar) |
